Body Temperature Solution (BTS)
Thermographic Bullet Body Temperature Measurement Camera is able to measure object's temperature at a high accuracy in real time. It is capable to discover and track people with higher body temperature among the crowded public area, it can be widely used in places such as customs, airport, school and hospital for inspection and quarantine.
Key Features: » 160 × 120 resolution in thermal channel, high sensitivity sensor. » Point, line and area for temperature measurement » Temperature range: 30°C to 45°C; temperature accuracy: ±0.5 °C » Reliable temperature exception alarm function » 3D DNR, image detail enhancement » Strobe light and audio alarm Advantages: » Thermographic turret / bullet support human temperature-exception audio alarm to notice the operator in time. » Easy installation and simple configuration. » Support AI face detection, multiple targets screening at the same time, reduce false alarms. » Accuracy is ±0.5 degree, satisfy preliminary fever screening requirement |
Body Temperature Solution (BTS) - SpecificationBody Temperature Scanner - Main Module |
| Image Sensor | Vanadium Oxide Uncooled Focal Plane Arrays | ||
| Max. Resolution | 160 × 120 (the resolution of output image is 320 × 240) | ||
| Pixel Interval | 17μm | ||
| Response Waveband | 8 μm to 14 μm | ||
| NETD (Noise Equivalent Temperature Difference) | ≤ 40 mk (@25 °C, F# = 1.1) | ||
| Lens (Focal Length) | 6.2 mm | ||
| IFOV | 2.74 mrad | ||
| Field of View | 25° × 18.7° (H × V) | ||
| Min. Focusing Distance | 0.6 m | ||
| Aperture | F1.1 | ||
| Temperature Measurement | 3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line). | ||
| Temperature Range | 30°C to +45 °C | ||
| Temperature Accuracy | ±0.5°C | ||
| Power Consumption | 12 VDC ± 20%: 0.65 A, max. 7.5 W
PoE (802.3af, class 3): 42.5 V to 57 V, 0.14 A to 0.22 A, max. 8 W |
| Temperature Calibrator |
| Radiation source temperature | 5°C ~ 50°C, adjustable | ||
| Temperature Resolution | 0.1°C | ||
| Temperature Accuracy | +-0.1°C | ||
| Temperature Stability | +-0.1°C/h | ||
| Effective Emissivity | 0.97+-0.02 | ||
| Effective Radiation Surface | 70mm x 70mm | ||
| Power Supply | 220V, AC50Hz | ||
| Working Temperature | 0°C ~ 30°C |
|
|
|
|
